Frequently Asked Questions
1. What is the maximum speed supported by this control cabinet?
The system supports elevator speeds up to ≤2.5m/S, making it suitable for a wide range of residential and commercial buildings.
2. How many floors can this system manage?
The control cabinet supports a maximum expansion of up to 48 floors using its advanced serial signal sampling mode.
3. Which motor types are compatible with the MONT70 controller?
It is designed for universal compatibility, working seamlessly with both synchronous and asynchronous elevator motors.
4. What are the dimensions and power range of the cabinet?
The cabinet size is 600*240*1010mm, and it covers a power range from 2.2KW up to 15KW.
5. What voltage supply is required for operation?
The standard power supply requirement is Three Phase, AC380V-460V, at 50/60Hz.
6. Is a computer room required for this installation?
No, this is a small machine room/machine roomless compatible design, allowing for more flexible architectural planning.
