⚡ Basic Specifications
| Model NO. | LPV-100-12, LPV-100-24 | Output Power | 100W |
|---|
| Input Voltage | Full Range | Connection Mode | Series Switching Power Supply |
|---|
| Voltage Mode | Width Modulation Type | Certification | CE, RoHS |
|---|
| Dimensions | 183*71*47mm | Weight | 0.53kgs |
|---|
| Guarantee | 2 Year Case | Output Frequency | 47-63Hz |
|---|
| Condition | Original New | HS Code | 8504401990 |
|---|
📋 Product Features
✔ AC input range selectable by switch
✔ Protections: Short circuit / Overload / Over voltage
✔ Cooling by free air convection
✔ LED indicator for power on
✔ 100% full load burn-in test
✔ High efficiency, long life and high reliability
📊 Technical Data Sheet
| Model |
LPV-100-12 |
LPV-100-24 |
| Output | DC Voltage | 12V | 24V |
| Rated Current | 8.5A | 4.5A |
| Rated Power | 102W | 100.8W |
| Ripple & Noise | 100mvp-p | 150mvp-p |
| Input | Voltage Range | 90~264VAC, 126~373VDC |
| Efficiency | 82% | 84% |
| Leakage Current | <2.5mA/240VAC |
| Protection | Over Load | 105%~135% hiccup mode, auto-recovery |
| Over Voltage | 15.6~17.8V | 30.6~33.2V |
| Over Temp. | Shell ≥85ºC, cutoff output, auto-recovery |
| Safety | Standard | Fit UL1012, IP67 protection level |
📦 Trade & Service Information
| Trade Terms | FOB, CIF, CFR, EXW, DDP |
Payment | T/T, L/C, Western Union, Paypal |
| Delivery Time | 3-7 working days |
Packing | Neutral carton or Export standard |
🖼️ Product Display
❓ Frequently Asked Questions
Is the LPV-100 power supply truly waterproof?
Yes, it is designed with an IP67 protection level, making it suitable for waterproof applications and internal/external environments.
What types of protections does this power supply offer?
The LPV-100 includes comprehensive protection against short circuits, overloads, over voltage, and over temperature (shell temperature ≥85ºC).
What is the difference between the LPV-100-12 and LPV-100-24?
The LPV-100-12 provides a 12V DC output with 8.5A current, while the LPV-100-24 provides a 24V DC output with 4.5A current. Both have roughly 100W total power.
What is the warranty period for this unit?
This product comes with a 2-year warranty covering normal operating conditions.
Can this power supply handle different input voltages?
Yes, it supports a wide input range of 90~264VAC or 126~373VDC, making it compatible with most global power systems.
What is the typical delivery time for orders?
Standard delivery usually takes 3-7 working days after deposit, or 2-4 working days if the item is currently in inventory.
