Smun Lrs-350-12 350W 12VDC 29A AC-DC Industrial Switching Power Supply

1 / 5

Smun Lrs-350-12 350W 12VDC 29A AC-DC Industrial Switching Power Supply

Still deciding? Get samples of $ !

Order Sample

Send Inquiry

Product Description

■ Basic Specifications

Model NO.

LRS-350-12

Output Power

301 - 400W

Input Voltage

85~132VAC/170~264VAC by Switch

Connection Mode

Series Switching Power Supply

Output

12VDC 29A

Power

350W

Efficiency

88%

Certification

CE, ISO, CCC

Size

215*115*30mm

Weight

0.76kg

Frequency

47~63Hz

Protection

Short Circuit/Overload/Over Voltage/Over Temp

■ Technical Parameters

Model	LRS-350-5	LRS-350-12	LRS-350-15	LRS-350-24	LRS-350-36	LRS-350-48
Dc output voltage	5V	12V	15V	24V	36V	48V
Rated output current	60A	29A	23.2A	14.6A	9.7A	7.3A
Rated Power	300W	348W	348W	350.4W	349.2W	350.4W
Voltage tolerance	±3%	±1.5%	±1%	±1%	±1%	±1%
Efficiency	83.5%	85.0%	86.0%	88.0%	88.5%	89.0%
Input voltage	AC85~132AC/170~264V By switch 47~63Hz; 240~370VDC

■ Product Display

■ Frequently Asked Questions

What is the input voltage range for the LRS-350 series?

The unit supports a wide input range of 85~132VAC or 170~264VAC, which is selectable by a manual switch to suit different regional power standards.

What kind of protections are built into this power supply?

It includes multiple safety protections: Short Circuit, Overload (110%~140% hiccup mode), Over Voltage, and Over Temperature protections.

Does this product carry any international certifications?

Yes, the power supply is certified by CE, ISO, and CCC, and is designed to meet standards like EN60950 and UL60950.

What is the operating temperature range?

The unit is designed for industrial environments and can operate reliably in temperatures ranging from -30°C to +70°C.

What is the efficiency rating of the 12V 29A model?

The LRS-350-12 model features a high efficiency rating of approximately 88%, ensuring minimal energy waste during operation.

Can the output voltage be adjusted?

Yes, there is a voltage adjustment range. For the 12V model, the output can typically be adjusted between 10.2V and 13.8V.
